If you have an Angling Technics Graphic Echo and an iPhone or iPad...

You can have an amazing high resolution colour upgrade using our new Bluesounder device...

subscribe to newsletter
If you have an Angling Technics Graphic Echo and an iPhone or iPad...

What is Bluesounder?

Bluesounder is essentially a stand alone accessory which converts the radio transmissions received from the standard echo sounder in an Angling Technics Microcat, Technicat or even original standard baitboat to a signal that connects to an Apple iPhone or iPad. Effectively your iPhone/iPad becomes a full blown high resolution, narrow beam, full colour echo-sounder display with up to four hundred times the picture resolution of the low resolution monochrome LCD handset which was originally supplied with the boat. It consists of a small black box with a removable antenna, an on/off switch and a bankstick thread with power provided by way of three ‘AA’ batteries. Bluesounder works with any Angling Technics baitboat with echo sounder version 1.4 and later (from February 2008). There is a completely free app available from the iTunes store which allows you to choose from several colour schemes, bottom surface indication, units and contact visibility. The display can be frozen, swiped back in time so that the last few minutes of depth profile can be reviewed and the units, speed and zoom levels can all be changed to suit the user and conditions. A radio transmission strength indicator(from the baitboat) and Bluesounder battery condition meter are present to provide all the information you need to survey your venue and find that perfect spot. Bluesounder uses the latest incredibly efficient BLE (Bluetooth® Low Energy) system also known as Bluetooth 4 which uses a fraction of the power that previous versions of Bluetooth did and subsequently has almost no effect on iPhone/iPad operating time.

Up close

Up close

An echo signal source

Microcat HD with echo
An echo signal source

The App

Main screen

Main screen

This is the main display of the app which shows a moving chart of the water bed underneath your baitboat. On screen is also the realtime depth, battery condition and radio signal strength indicators.

Settings

This screen allows you to select the colour scheme , the surface variation index (S.V.I.), the visibility of non-bottom contacts and the units in Metres or Feet.
Settings
Connect screen

Connect screen

Connect your iPhone/iPad to Bluesounder using this very simple form.

FAQ

Doesn't Bluetooth drain my phone battery really quickly?

No, not this latest new version 4 or BLE (Bluetooth Low Energy) It is far better in terms of battery life and efficiency than the previous, older Bluetooth system. We ran a fully charged iPhone 5S connected to Bluesounder for 24 hrs and it dropped to 88% full. We charged it back up, turned off Bluetooth and measured it again after 24 hrs - the same 88% - enough said!

How often do I need to change Bluesounder's batteries?

Standard off the shelf alkaline Batteries will last up to 250 hours, so enough for most sessions. You can also use rechargeable batteries if you wish.

Which devices work with Bluesounder?

iPhone 4S, 5S,5C,6, 6+, 6S, 6S+, iPod Touch (5th gen), iPad 3rd generation, 4th generation, mini, mini 2, mini 3, Air & Air 2

Will Bluesounder interfere with my phone calls, browsing etc?

No, you can run your device exactly as before, taking and making calls as before.

Does Bluesounder work with any Baitboat echo?

It is designed to work with any Angling Technics installed echo from version 1.4 (2008 onwards). You do not need the Graphic handset to use Bluesounder, and no work on your boat is required.

What is the range of the Bluesounder?

Up to 300 metres between the boat and Bluesounder. Up to 50 metres between your iPad/iPhone and Bluesounder.

Bluesounder

£395.00

Bluesounder
Bluesounder Bluesounder

Bluesounder

£395.00

has been successfully added to your cart . Feel free to continue shopping or check out .

Bluesounder comes complete with removable antenna, instructions, and a one year guarantee.
